BERG PlayBase Extra Large - XL

BERG PlayBase Extra Large

The biggest PlayBase. 4.9m wide with eight carabiner points — twice the Medium's capacity, and enough that a large family never runs out of places to hang things.

It's the size that suits teenagers and adults as much as young children.

---

Specification

Frame width	4.9m
Depth	1m
Height	2.45m
Clear space needed	8.5m × 6m
Carabiner points	8
Swing-type accessories at once	4 (most use two carabiners)
Maximum load	400kg total
User age	3+ years
Material	Powder-coated steel
Frame weight	134kg
Colours	Green or black
Configurations	TL, TT or LL

The 400kg is a total load rather than per person, which is why several children can use it at once — unlike a trampoline, where one at a time is the rule.

---

Eight carabiner points

Most accessories use two carabiners, so eight points is four swing-type accessories — plus the single-point items like a boxing bag or basketball hoop alongside them.

That's a garden that doesn't need managing. Four children, four things, and still somewhere to hang a hoop.

It's also the frame that works as a serious outdoor gym — rings, fitness rope and resistance bands with points left over for the children.

The trade is ground. You need 8.5m × 6m of clear space. If that's more than you have, the Large takes six accessories in 7m × 5m and is the size most families settle on.

---

Every accessory fits

Swings, climbing wall, climbing net, gym rings, trapeze, basketball hoop, soccer goal, boxing bag, dip bar, pull-up bar, fitness rope, resistance bands, baby seat, nest swing, platform and slide — all of them fit this frame.

The one exception across the range is the hammock, which needs the Large frame.

See all PlayBase accessories.

---

TL, TT or LL?

The frames come with different top sections:

• TL — tumble bar and ladder. The most popular by a distance, and what we'd suggest if you're unsure.
• TT — two tumble bars. For children who spend their time spinning and hanging rather than climbing.
• LL — two ladders. Monkey-bar style, for climbing and traversing.

Available in green or black.

---

It grows with them

This is why a PlayBase outlasts a swing set. The frame never changes; what hangs off it does.

• Toddler — baby seat, nest swing
• Primary school — monkey bars, climbing wall, trapeze, rings
• Teenager — boxing bag, pull-up bar, basketball hoop
• Adult — gym rings, dip bar, fitness rope, resistance bands

Swap accessories over an afternoon rather than replacing the whole thing.

---

Space planning

The frame footprint isn't the whole story — allow for what's hanging off it.

• Swings need about 2 metres clear in front and behind for the arc
• Climbing wall wants around 1.5 metres clear and soft ground beneath
• Basketball hoop is better with 3 to 4 metres in front
• Keep it clear of fences and hedges — children swing higher than you expect

Grass is fine. On a hard surface, use protective matting. More in our sizes and dimensions guide.

---

Warranty and certification

Warranty	10 years, or 13 years with registration
CE marked	Yes
GS mark (TÜV)	TÜV SÜD Mark P

Registering adds three years — free, and it takes five minutes. Ring us if you can't find your batch number and we'll dig it out.

---

The PlayBase range

Every frame is 1m deep and 2.45m high. What changes is the width — and the number of carabiner points. Most accessories use two, so the carabiner count roughly halves into swing-type items.

	Wall	Medium	Large	Extra Large
Carabiner points	3	4	6	8
Swing-type accessories	1-2	2	3	4
Frame width	1.2m	2.85m	3.8m	4.9m
Clear space needed	4m × 3m in front	6m × 4m	7m × 5m	8.5m × 6m
	Wall	Medium	Large	You are here

---
